Abelflex

Abelflex

EXPANSION JOINT AND SPACE FILLER (Zip Rolls)

A flexible, lightweight, closed cell, cross-linked, polyethylene foam expansion joint and space filler. In concrete and brickwork Abelflex has excellent recovery properties.

• Non-absorbent.
• Excellent recovery after compression.
• Readily compressible.
• Seals gaps against dust and water entry.
• Non-bleeding and resistance to fungi and insect attack (approved to AS2170) making it ideal for use in food contact applications.
• Easy to work with and cut.
• Resistant to most chemicals.
• Compatible with most liquid sealants.
• Lightweight and can be easily handled on-site.
• Can be easily moulded to suit more applications.
Product Data Sheet Show all documents

Usage

  • Ideal as a gap filler and bond breaker for floor and wall expansion joints, filling systems for roads, motorways, bridges, walls and automotive  applications.
  • In joints where polystyrene or bitumen impregnated fillers have been used, Abelflex is ideal as a bondbreaker. Often necessary because of the sealant incompatibility with these forms of fillers.
  • Suitable as a back-up filler for most liquid sealants
  • Ideal for stopping contaminants such as soil entering into expansion slots and joints


Advantages

• Non-absorbent.
• Excellent recovery after compression.
• Readily compressible.
• Seals gaps against dust and water entry.
• Non-bleeding and resistance to fungi and insect attack (approved to AS2170) making it ideal for use in food contact applications.
• Easy to work with and cut.
• Resistant to most chemicals.
• Compatible with most liquid sealants.
• Lightweight and can be easily handled on-site.
• Can be easily moulded to suit more applications.

Packaging

10mm x 75mm x 25m

10mm x 50mm x 25m

10mm x 100mm x 25m

10mm x 150mm x 25m

Colour

Dark Grey Foam

Product Details

Product Information

Composition

Polyethylene Foam

Shelf life

When stored in dry conditions this product has an unlimited shelf life.

Storage conditions

Cool dry area free from direct sunlight.

Density

25 Kg/m3
Technical Information

Tensile strength

Longitudinal 0.21 Mpa                                                                          (ISO 1798)

Transversal 0.16 Mpa                                                                            (ISO 1798)



Tear propagation resistance

Longitudinal 0.60 N/mm                                                                     (DIN 53507)

Transversal 0.60 N/mm                                                                       (DIN 53507)

Chemical resistance

  • Water
  • Sea water & brine
  • Soap and detergents
  • Diluted acids
  • Diluted detergents
  • Alcohol
  • Fungi

Thermal conductivity

0.05 W/mk                                                                                              (JIS A1412)

Service temperature

-40° C Min / +95° C Max                                                                        (ISO 1856)

Compression resistance

Compression set (22N, 25%, 23° C)           0.5 hrs       < 19%            (ISO1856)

                                                                         24 hrs        < 10%            (ISO 1856)
